Sony Develops Back-Illuminated Time-of-Flight Image Sensor With the Industry's Smallest Pixel Pitch

Published: Jun 05,2017

Comparison of obtained depth map at the same distance: New sensor (left) and conventional sensor (right)

Sony Corporation today announced it has developed a back-illuminated time-of-flight ("ToF") image sensor with a 10µm pixel pitch, the industry's smallest.

More on This

Sony Easily Maintains Its Top Ranking in the Diverse O-S-D Market

IC Insights noted that only four of the top-10 companies sell products in all three O-S-D market segments. The 10 large...

Sony and DOCOMO to Test Driverless Concept Vehicle via 5G Trial Network in Guam

Sony and NTT DOCOMO announced today that they will jointly trial Sony's conceptual driverless vehicle, the New Concept Cart SC-1...

This accomplishment was made possibly combining the ToF image sensor technology of Softkinetic Systems S.A. ("Softkinetic"), a Sony subsidiary acquired in 2015, and Sony's back-illuminated CMOS image sensor technology.

With ToF technology, the distance to an object is measured by the time it takes for light from a light source to reach the object and reflect back to the sensor. ToF image sensors detect distance information for every pixel, resulting in highly accurate depth maps.

Accuracy can be enhanced even further by ensuring that the reflected light is efficiently received and that the processing required to measure distance is executed at a high frame rate. Additionally, power consumption can be reduced by efficiently collecting and processing the reflected light; the more efficient, the less light source power is needed.

At the heart of the ToF technology in Sony's new product is Softkinetic's proprietary Current Assisted Photonic Demodulator ("CAPD"), which employs a unique pixel architecture capable of high-speed modulation using drift current*3 in the pixel, allowing for detection of the light signal with an improved accuracy. This methodology raises the accuracy of distance measurement at the level of every pixel, thereby delivering accurate measurement and depth map acquisition even at significant distances.

Sony combined CAPD with its back-illuminated CMOS image sensor pixel technology to develop the new back-illuminated ToF image sensor, which features a 10µm pixel pitch, with the industry's smallest.*1 The new sensor builds on the advantages of a back-illuminated pixel structure, which layers the circuitry beneath the photo detector.

By optimizing the pixel construction and circuitry for CAPD, the new Sony product delivers improved light collection efficiency and enables high-speed distance measurement processing. The design delivers accuracy equivalent to conventional methods, even at 1.5x the distance.*2 The higher level of light collection efficiency also makes it possible to use a less-powerful light source, and this keeps power consumption down and allows the ToF camera module to be more compact.

In recent years, demand for more accurate depth sensing has been increasing, particularly in the fields of augmented reality (AR), virtual reality (VR), and other applications such as robotics and drones that require autonomous operations. This new sensor is part of the DepthSense lineup, which makes features such as gesture and object recognition as well as obstacle detection possible.
