Intel Showcases Industry’s First 64-Layer 3D NAND for Data Center, Updates for 10nm in China

Published: Sep 19,2017

Intel delivered key updates at its Technology and Manufacturing Day held in Beijing, China, on Sept. 19. Disclosures included power and performance updates for Intel’s 10 nm process, high-level plans for Intel’s first 10 nm FPGA, and an announcement that the company is shipping the industry’s first commercially available 64-layer 3D NAND for data center applications.

More on This

Intel and Mobileye Offer Formula to Prove Safety of Autonomous Vehicles

Mobileye and Intel today announced a formal, mathematical formula to ensure that a self-driving vehicle operates in a responsible manner and does not cause accidents...

Intel Unveils the 8th Gen Intel Core Processor Family for Desktop Featuring Best Gaming Ability

Intel today announced that its new family of 8th Gen Intel Core desktop processors will be available for purchase beginning Oct...

“Intel manufacturing processes advance according to Moore’s Law, delivering ever more functionality and performance, improved energy efficiency and lower cost-per-transistor with each generation,” said Stacy Smith, group president of Manufacturing, Operations and Sales. “We are pleased to share in China for the first time important milestones in our process technology roadmap that demonstrate the continued benefits of driving down the Moore’s Law curve.”

Smith added that Intel’s ability to advance Moore’s Law – to make products less expensive and more capable every year – is the company’s core competitive advantage. Intel’s role has been, and will continue to be, that of the technology leader driving Moore’s Law, and today, Intel has about a three-year lead in process technology.

Intel Senior Fellow Mark Bohr presented specification updates showing Intel’s 10 nm is a full generation ahead of other “10 nm” technologies in terms of both transistor density and transistor performance. Intel’s 10 nm technology has the world’s tightest transistor and metal pitches, created with hyper scaling, for the highest density in the industry. Hyper scaling is a term used by Intel to describe the 2.7x logic transistor density improvement attained on the company’s 14 nm and 10 nm processes. And, for the first time, Intel’s “Cannon Lake” 10 nm wafer was on public display.

Mark Bohr also presented his density metric proposal to continue the company’s efforts to dispel the node-naming confusion within the industry and standardize on a common measure of transistor density that facilitates easy comparison across different manufacturers.

Bohr also provided power and performance updates for Intel’s 22FFL, a compelling lower-power FinFET technology for mobile applications first introduced at Intel’s Technology and Manufacturing Day in March in San Francisco. The updates included best-in-class CPU performance of more than 2 Ghz with ultra-low power of more than 100x lower leakage. In addition, a 22FFL wafer was on public display for the first time.

Intel unveiled high-level plans for its coming generation of FPGAs using the 10 nm process technology and foundry platform. Introduced under the code name “Falcon Mesa,” the FPGA will offer new levels of performance to support the growing bandwidth demands of data center, enterprise and networking environments. For more, read the Falcon Mesa fact sheet.

During the Intel Developer Forum in San Francisco in August 2016, Intel Custom Foundry announced an agreement with ARM to accelerate the development and implementation of ARM SoCs on Intel’s 10 nm process. The results of this collaboration were highlighted with the display of a 10 nm test chip wafer containing ARM Cortex-A75 CPU cores implemented with industry standard design flows enabling performance in excess of 3 GHz.

Intel also announced that it is shipping of the industry’s first 64-layer, triple level cell (TLC), 3D NAND SSD (solid state drive) for data center applications. Designed to help customers significantly improve storage efficiency, the product has been shipping to select top-tier cloud service providers since early August.

Intel’s three decades of developing expertise in memory has resulted in an optimized 3D NAND floating gate architecture and manufacturing process. This process leadership has enabled Intel to quickly expand its 64-layer TLC SSD portfolio from the client product, introduced in June, to now include SSDs for use in data centers. The product will be made more broadly available by the end of this year.
