The power efficient IP40 embedded system supports 12V DC input with screw-lock and features a user-friendly AT/ATX DIP switch. The compact eBOX560-500-FL is suitable for Industrial Internet of Things (IIoT) solutions, digital signage, retail equipment, smart factory automation, thin clients, industrial controller systems and many more.

“The Axiomtek extremely compact eBOX560-500-FL has wide operating temperature ranges from -10°C to +50°C (-14°F to +122°F). It features IP40-rated anti-dust ingress protection, and is able to endure vibration up to 3G,” said Janney Lee, product manager of Embedded PM Division at Axiomtek. “The reliable fanless embedded box computer comes with full-featured I/O interface and one PCI Express Mini Card for wireless network connection. The embedded controller is definitely one of the best solutions for IIoT applications.”

The rugged industrial embedded computer, eBOX560-500-FL, is equipped with rich I/O connectivity including four USB 3.0 ports, one RS-232/422/485 port, one RS-232 port, two Gigabit Ethernet ports, two SMA type connector openings for antenna, and two HDMI ports. One 2.5” SATA HDD and one mSATA are available for storage. The space-saving fanless embedded platform supports Jumbo Frame (9.5K), wake-on-LAN (WoL), PXE Remote Boot and Teaming. It runs well with the Windows®8.1, Windows 10, and supports Axiomtek’s exclusive “AXView 2.0” monitoring software package. To fulfill various application needs, the eBOX560-500-FL supports VESA mount, wall mount and DIN-rail mount by optional requests.
