When compared to traditional optocouplers, ADI’s IS-IS certified digital isolators simplify circuits by reducing required PCB board space along with component cost and design complexity as multiple diodes and resistors are no longer needed. These IS-IS digital isolators also provide higher data rates for more efficient operation and reduce installation cost over other protection methods.

Additionally, the innovative digital isolators are ultra-low power, limiting the amount of energy required to isolate in hazardous areas. ADI’s ADuM144x quad digital isolation devices are available in a small 16-lead QSOP (2.5kV) and 20-lead SSOP (3.75kV) packages.

Analog Devices’ ADuM144x micropower 4-channel digital isolators based on proven iCoupler technology have enabled designers to implement isolation in designs without the cost, size, power, performance, and reliability constraints found with optocouplers. With more than 1.8 billion channels shipped, these magnetically isolated products are safe, reliable, and easy to use by combining high speed, complementary metal oxide semiconductor (CMOS) and monolithic air core transformer technologies.

Operating with supplies as low as 2.25 V, ADuM144x digital isolators are ideally suited for applications such as industrial field instruments. The new devices received intrinsically safe certifications from CSA-Sira and IECEx, global providers of testing and certification services.
