Alliance Memory New High-speed CMOS 16Gb Mobile LPDDR3 SDRAM

Published: Mar 01,2017

450 Read

Alliance Memory introduced a new high-speed CMOS mobile low-power DDR3 (LPDDR3) SDRAM designed to extend battery life in compact portable devices. Featuring low voltage operation of 1.2V/1.8V and a number of power-saving features, the 16Gb AS4C512M32MD3 is offered in the 11.0mm by 11.5mm 178-ball FBGA package.

More on This

Alliance Memory Introduces New Die Version for 2Gb and 4Gb DDR3 and DDR3L SDRAMs

To address the memory market's shortage of high-speed CMOS DDR3 and low-voltage DDR3L SDRAMs, Alliance Memory today anno...

Alliance Memory Launches New 32-Bit Wide 8Mb and 16Mb Fast SRAMs in 90-Ball TFBGA Package

Alliance Memory introduced new 8Mb and 16Mb x32 devices in the 90-ball 8mm by 13mm TFBGA package. Providing space-saving alternatives to solutions in larger 119-ball packages...

With each new product generation, designers of mobile devices such as smartphones, tablets, and virtual and augmented reality (VR and AR) headsets are tasked with providing more functionality in less space while using less power. To meet this demand, the LPDDR3 device released today features auto temperature-compensated self-refresh (TCSR) to minimize power consumption at lower ambient temperatures.

In addition, its partial-array self-refresh (PASR) feature reduces power by only refreshing critical data, while a deep power down (DPD) mode provides an ultra-low power state when data retention isn't required.

"Reducing IC power consumption can directly increase battery life in portable devices, so the applications for LPDDR3 SDRAMs in the consumer and mobile communication markets continue to grow," said David Bagby, president and CEO of Alliance Memory.

"At the same time, the number of suppliers for these devices is decreasing. Alliance Memory is offering designers a new alternative and shorter lead times for the low power consumption they require. Devices such as our new 16Gb AS4C512M32MD3 provide reliable drop-in, pin-for-pin-compatible replacements for a number of similar solutions in high-bandwidth, high-performance memory system applications."

Manufactured using a 20nm process, the AS4C512M32MD3 is internally configured as 8 banks x 32 Mbit x 32. The device offers high-speed operation with a clock frequency of 667MHz and data rate of 1333Mbps, and it features an extended commercial temperature range of -25°C to +85°C.

The LPDDR3 SDRAM offers fully synchronous operation and programmable read or write burst lengths of 4, 8, or 16. An auto pre-charge function provides a self-timed row pre-charge initiated at the end of the burst sequence. Easy-to-use refresh functions include auto- or self-refresh. The RoHS-compliant device is lead (Pb)- and halogen-free.
