Axiomtek Announces Qseven Module with Intel Apollo Lake Processor – Q7M311

Published: Jun 19,2017

499 Read

Axiomtek announced the release of the Q7M311, a brand new Qseven module with Intel Apollo Lake processor, dual display interfaces, 32GB eMMC memory, and wide operating temperature supported.

More on This

Axiomtek’s COM Express Type 10 Mini Module Offers High Graphics Capability- CEM311

Axiomtek introduces the CEM311, its COM Express Type 10 Mini module featuring Intel Apollo Lake processor, high graphics capabilities...

Axiomtek COM Express Type 10 Mini Module Offers High Graphics Capability

Axiomtek introducied the CEM311, its COM Express Type 10 Mini module featuring Intel Apollo Lake processor, high graphics capabilities...

Axiomtek’s Q7M311 has adopted the 14nm Intel Pentium N4200 and Celeron N3350 quad-core/dual-core processors (codename: Apollo Lake). The extremely small embedded module supports 4GB (or optionally up to 8GB) DDR3L memory onboard and 32GB eMMC flash memory (optional). With a seismic design and for industrial-grade temperatures, both the CPU and the DDR3L RAM are soldered to deliver reliable and excellent computing performance. With rich features embedded in all the components built in a small form factor, the industrial-grade computer-on-module is aimed for industrial IoT applications, including industrial control, medical imaging, digital signage, gaming machines, military, and networking.

The Q7M311 - Axiomtek’s new Qseven module in a small form of 70 mm x 70 mm - was built to withstand a wide operating temperature range from -20°C to +70°C (i.e. -4°F to +158°F) for portable and rugged industrial applications. The extreme compact embedded SBC supports smart battery function with its onboard system memory and eMMC flash memory.

Additionally, incorporating Intel Gen 9 graphics, the newest Qseven module is delivering excellent graphics performance while supporting DX12.0, OCL 2.0, and OGL 4.3. Moreover, dual-display is supported with resolution up to 4K (3840 x 2160 @ 30 Hz) through two DDI ports: HDMI, DVI (/VGA optionally), and LVDS as well as an optional embedded DisplayPort. The capability of powerful media processing has made the Q7M311 an outstanding multimedia solution.

This Intel Apollo Lake-based computer-on-module is equipped with advanced connectivity, including four PCIe x1 ports, two USB 2.0 ports, four USB 3.0 ports, one Gigabit Ethernet (built-in Intel Ethernet controller i211AT), two SATA-600 interfaces, and eight inputs/outputs of general purpose for peripheral devices and data transfer. Also, the LPC bus is available for easy connection of legacy I/O interfaces. This powerful Qseven embedded board runs well with Windows®10 and Linux operating system and supports Axiomtek AXView 2.0 intelligent remote management software.
