Axiomtek’s COM Express Type 10 Mini Module Offers High Graphics Capability- CEM311

Published: Aug 15,2017

402 Read

Axiomtek introduces the CEM311, its COM Express Type 10 Mini module featuring Intel Apollo Lake processor, high graphics capabilities, a wide temperature range, and rich I/O options in a compact form factor.

More on This

A Desktop Network Appliance Platform Built on Intel Denverton Supporting Intel QAT – NA362

Axiomtek is announcing the NA362, its latest compact network appliance platform powered by the low power consumption Intel Atom processor C3538/C3758 (Codename: Denverton)...

Axiomtek COM Express Type 10 Mini Module Offers High Graphics Capability

Axiomtek introducied the CEM311, its COM Express Type 10 Mini module featuring Intel Apollo Lake processor, high graphics capabilities...

The new CEM311 is designed to support the Intel Pentium N4200 quad-core and Celeron N3350 dual-core processors (codename: Apollo Lake). Integrated with Intel Gen 9 graphics, the CEM311 with the support of DX12.0, OCL 2.0, OGL 4.3 delivers outstanding graphics computing, 4K resolutions and media performance.

The rugged system on module supports a wide operating temperature range from -20°C to +70°C to ensure stable operation in harsh environments. The embedded platform offers onboard 4GB or 8GB of DDR3L memory and an optional eMMC flash up to 64GB. Overall, the CEM311 can be served as an excellent solution for graphics-intensive applications over the Industrial IoT, including industrial control, medical imaging, digital signage, gaming machines, military, and networking.

“Axiomtek's credit card-sized “CEM311” adopts Intel latest Apollo Lake dual-core or quad-core processor. It provides a balanced overall performance for the applications which need low power consumption, high performance, and rich graphics. The tiny system-on-module is ideally suitable for handheld, portable or mini devices.” said Seamus Su, a product manager of EPDE PM Division at Axiomtek.

In addition, Axiomtek's CEM311 comes with rich I/O options including four PCI Express lanes, two SATA-600, one Gigabit LAN with Intel i211AT Ethernet controller, two USB 3.0, eight USB 2.0, one LVDS, one DDI, and four digital I/O channels. Also, one LPC bus is available for easy connection of legacy I/O interfaces. With a wide voltage range of 4.75V - 20V DC-in power input, the module is designed to satisfy a wide range of vertical embedded applications. This new low power COM Express type 10 Mini module runs under Windows 10 and Linux operating systems and supports Axiomtek AXView 2.0 - intelligent remote management software exclusively offered by Axiomtek.

With over 25-year experience in design-in services and customized thermal solutions, the Company has been presenting a wide array of embedded systems along with software and modularized accessories to meet different levels of customized services. Axiomtek Technical Portal (ATP), a web-based support service, allows users to download up-to-date technical design guides, mechanical 2D/3D drawings, and software utilities simply through a click on the ATP web page.
