HOLTEK New BC3601 Sub-1GHz FSK/GFSK RF Transceiver IC

Published: Jan 08,2018

786 Read

Holtek announces the release of its new bidirectional wireless FSK/GFSK high performance transceiver IC, the BC3601. This device, which operates in the 300MHz~960MHz license-free ISM bands, is suitable for battery or IoT applications that require low power consumption, such as smart homes, intelligent security products, car alarms, industrial/agricultural controllers and many other wireless bidirectional communication products.

More on This

HOLTEK New HT45B0016 Wireless Charger Transmitter’s Power Stage

Directly aimed at the wireless charger transmitter application area, Holtek presently announces the release of its new two-in-one half-bridge power device, the HT45B0016...

HOLTEK New BS83B24C/BS83C40C High Key Count High Anti-interference Touch MCUs

Holtek announced the release of a new generation of Touch Flash MCUs, the BS83xxxC series. In addition to including all the advantages of the already released BS83BxxA series...

The BC3601 includes a fully integrated high power programmable amplifier, a frequency synthesizer and a digital demodulation function, etc., greatly simplifying the peripheral circuit design. The RF characteristics of the device are compliant with ETSI/FCC specifications.

The device has an operating voltage ranging from 2.0V to 3.6V and a programmable transmitting power up to +17dBm. Its receiving sensitivity is up to -118dBm at a data rate of 2kbps and its transmission rate is up to 250kbps. The device also includes an ATR (Auto-Transmit-Receive) function and an integrated high precision, low power oscillator for WOT (Wake-on-TX) and WOR (Wake-on-RX) functions.

The BC3601 includes an SPI control interface and meets with the industrial specification operating temperature of -40°C ~ 85°C. It is supplied in a small 24-pin QFN (3mm×3mm) package type which will meet the requirements of thin profile wireless product and module designs.
