Toshiba's New Three-Phase Brushless Fan Motor Driver IC Has a Rotation Speed Control Function

Published: Mar 29,2018

1270 Read

Toshiba Electronic Devices & Storage Corporation announced the launch of “TC78B025FTG,” a three-phase brushless motor driver IC with a rotation speed control (closed loop control) function, for application in small fans used in home appliances and industrial equipment. Mass production will start from April.

More on This

Toshiba Releases Automotive 40V N-channel Power MOSFETs in New Package

Toshiba Electronic Devices & Storage Corporation has released two new MOSFETs “TPHR7904PB” and “TPH1R104PB” housed in the small low-resistance SOP Advance (WF) package...

Toshiba Releases Medium-voltage Photorelay in Small 4-pin SO6 Package for Factory Automation

Toshiba Electronic Devices & Storage Corporation has released “TLP176AM,” a new photorelay in a small 4-pin SO6 package...

The cooling fans used in servers and other must be small and rotate at high speeds with uniform accuracy. Uniformity is best achieved by using a speed-feedback method to suppress fluctuations in rotation speed caused by changes in power supply voltage and load. Until now, this has required the use of microcomputers, but Toshiba’s new solution achieves flexible rotation speed control without external microcomputers by incorporating a non-volatile memory (NVM). This also allows easy system configuration.

In addition, TC78B025FTG implements a 1-Hall drive system and current sense resistor-elimination system to reduce the number of external components and contribute to the space saving on boards. Industry-leading [1] low ON resistance (0.2Ω (typ.) (total of high and low sides)) reduces the IC’s self-heating during operation, so extending support to large current drives.
