Toshiba Releases Medium-voltage Photorelay in Small 4-pin SO6 Package for Factory Automation

Published: Apr 09,2018

440 Read

Toshiba Electronic Devices & Storage Corporation has released “TLP176AM,” a new photorelay in a small 4-pin SO6 package, for factory automation and other industrial applications. TLP176AM has a rated on-state output terminal voltage of 60V and a rated on-state current of 0.7A. Volume shipments begin today.

More on This

Toshiba Releases Interface Bridge Devices for Automotive Infotainment Applications

Toshiba Electronic Devices & Storage Corporation announces a new range of video interface bridge devices intended for mo...

Toshiba Memory Corporation and Synopsys Collaborate to Accelerate 3D Flash Memory Verification

Synopsys announced that it has collaborated with Toshiba Memory Corporation to accelerate the verification of Toshiba Me...

TLP176AM incorporates MOSFETs fabricated with the latest U-MOS IX process, and supports an on-state current of up to 0.7A. It also provides higher ESD immunity than the current TLP172AM, with a rated on-state current of 0.5A. The new photorelay is upwardly compatible with TLP172A, Toshiba’s major photorelay in a 2.54SOP4 package with a rated on-state current of 0.4A, in terms of both performance and footprint.

TLP176AM is suitable for use as a replacement for 1-Form-A mechanical relays—replacing mechanical relays with photorelays helps to improve system reliability and reduce the space required for relays and relay drivers. As TLP176AM has a rated operating temperature of up to 110ºC (max), it is also easier to allow for a temperature margin in system-level thermal design.
