Toshiba Electronic Devices & Storage Corporation has obtained US safety standard UL508 certification for the following e...
Toshiba Electronic Devices & Storage Corporation announces the launch of a new Schottky barrier diode product “CUHS10F60...
Fabricated using the latest ninth generation trench U-MOS IX-H process and housed in a small low-resistance package, the new MOSFETs provide low on-resistance and thus help reduce conduction loss. The U-MOS IX-H design also lowers switching noise compared with Toshiba’s previous design (U-MOS IV), helping to reduce EMI (Electromagnetic Interference).
The SOP Advance (WF) package adopts a wettable flank terminal structure, which enables AOI (Automated Optical Inspection) after soldering.
