HOLTEK New HT68F2422 IR Driver MCU

Published: Jul 09,2018

217 Read

Holtek announced the release of its new IR driver MCU, the HT68F2422, especially designed for use in IR remote controller and IR transmission related product applications. This new device includes an integrated high precision oscillation circuit with a frequency tolerance of ±0.4% and an IR emitting diode driver circuit which can provide a 500mA drive current. These features allow savings on an external oscillator and drive transistor thus reducing the external component cost and improving the product yield.

More on This

HOLTEK New HT32F67233 Sub-1GHz GFSK Transceiver Arm Cortex -M0+ MCU

Holtek announces the release of its new wireless communication dedicated MCU, an Arm Cortex-M0+ core Sub-1GHz GFSK transceiver, the HT32F67233...

HOLTEK New BC66F2143 Sub-1GHz RF Transmitter MCU

Holtek announces the release of its new Sub-1GHz RF OOK/FSK Transmitter Flash MCU, the BC66F2143. This new device, which can operate in the license-free ISM bands...

The device includes a 4kHz~1MHz IR carrier frequency generator. Together with the Holtek supplied development tools, four common IR carrier frequencies of 36, 38, 40 or 56kHz can be selected. The internal oscillator frequency can be trimmed to 3.996, 3.99, 4.0, or 3.976MHz, allowing the frequency error to be effectively reduced to ensure better matching of the transmitter and receiver carrier frequencies and thus increasing the IR transmission range.

The device has an operating voltage range of 1.8V~5.5V and includes a Flash program memory capacity of 1Kx13 and a RAM data memory capacity of 32x8. The device also provides a 9-bit Timer as well as Time Base functions. The fully internal 4MHz oscillator has a high precision frequency specification with a tolerance of ±0.4% at a voltage range of 1.8V~5.5V and with an operating temperature of -10℃ ~ 50℃. This oscillator is used as the MCU main system clock allowing the device to operate with a more accurate frequency. The device is supplied in 8-pin SOP, 16-pin NSOP, 20-pin NSOP and 20-pin SSOP package types.
