HOLTEK New BS86D20C High Noise Immunity A/D Touch MCU

Published: Dec 13,2018

129 Read

Holtek announced a new generation A/D Type Touch Flash MCU, the BS86D20C. This new device provides up to 20 touch keys all of which have the feature of high noise immunity. The device also provides an enhanced range of system resources in addition to a larger LED drive current. These features combine to ensure the device is suitable for use in applications which require multiple touch key functions, temperature detection and LED display functions. Applicable products could be electric pressure cookers, high speed blenders, rice cookers and other related home appliances with LED displays as well as many others.

More on This

HOLTEK New HT32F67233 Sub-1GHz GFSK Transceiver Arm Cortex -M0+ MCU

Holtek announces the release of its new wireless communication dedicated MCU, an Arm Cortex-M0+ core Sub-1GHz GFSK transceiver, the HT32F67233...

HOLTEK New BC66F2143 Sub-1GHz RF Transmitter MCU

Holtek announces the release of its new Sub-1GHz RF OOK/FSK Transmitter Flash MCU, the BC66F2143. This new device, which can operate in the license-free ISM bands...

With their excellent noise immunity, the BS86xxxC series can resist various types of noise interference such as power noise, RF interference, power fluctuations, etc. The devices have all passed the conductive susceptibility dynamic 10V test. This new device has an operating voltage of 2.2V~5.5V, 20 touch keys, a 4-level optional LVR voltage range of 2.1V~3.8V and an 8-channel A/D converter.

The device also includes a 10-bit Compact Timer Module and two 10-bit Periodic Timer Modules for PWM output generation. Additional features include an LED drive current of up to 100mA as well as SPI, I2C and UART communication interfaces. The device is supplied in 24/28-pin SOP package types whose pin definitions are fully compatible with the BS86D20A-3 and thus can act as a replacement without requiring a PCB re-design.

The BS86xxxC series devices are suitable for use as master MCUs, which when used together with a suitable power board can implement product applications. Holtek also fully supports the device series with a comprehensive suite of hardware and software development tools. The supporting software includes a touch key function library which enables designers to develop their products more rapidly by eliminating the need to write code for the touch key functions. The Holtek hardware development tool is known as the e-Link which works together with an OCDS evaluation MCU to provide users with an actual MCU device with which real emulation and debug can be implemented, thus reducing significantly the development to market time.
