HOLTEK New BH67F2132 1.1V R to F MCU

Published: Dec 18,2018

314 Read

Holtek announces the release of its new 1.1V R to F Flash MCU, the BH67F2132 device. The device has a minimum operating voltage of 1.1V, which is suitable for various single-battery powered temperature measurement products, such as thermometers and indoor/outdoor temperature measurement applications.

More on This

HOLTEK New HT68F0021/HT68F0031 Cost-Effective MCUs

Holtek wishes to announce two new additions to its Cost-Effective Flash MCU range with the release of the HT68F0021 and HT68F0031 devices...


In expanding its presence in the Brushless DC Motor controller application area, Holtek is delighted to announce its new BLDC Flash type MCU, the HT66FM5340...

The BH67F2132 has integrated two sets of independent measurement resistance/frequency (R to F) conversion circuits which do not require any voltage step-up components. The use of Flash type memory allows for increased flexibility during product development while its integrated true EEPROM memory can be used to store calibration data, thus greatly reducing production time and cost.

With regards to other system resources, the device includes 2K words of Flash Program Memory, 128 bytes of Data Memory and 128 bytes of True EEPROM Memory. As for packaging, the device is supplied in a 48-pin LQFP package type.
