HOLTEK New HT32F0006 Arm Cortex-M0+ Core 32-bit Voice/Music Synthesis Dedicated MCU
Published: Jan 07,2019497 Read
Aimed at the voice/music application field, Holtek announces the release of its new 32-bit SoC Flash MCU, the HT32F0006, which is based around an Arm Cortex-M0+ processor core. In having a 32-bit MCU for its voice and music processing, the device offers both high performance and high quality audio and can be used to implement superior sound effect functions. This makes it suitable for use in products such as electronic organs, electronic pianos, electronic drums and higher level voice and musical toys to name but a few.
HOLTEK New HT32F67233 Sub-1GHz GFSK Transceiver Arm Cortex -M0+ MCU
Holtek announces the release of its new wireless communication dedicated MCU, an Arm Cortex-M0+ core Sub-1GHz GFSK transceiver, the HT32F67233...
HOLTEK New BC66F2143 Sub-1GHz RF Transmitter MCU
Holtek announces the release of its new Sub-1GHz RF OOK/FSK Transmitter Flash MCU, the BC66F2143. This new device, which can operate in the license-free ISM bands...
The HT32F0006 provides 128K bytes of Flash memory and 16K bytes of Data RAM memory. When operating at its maximum system frequency of 48MHz, the integrated MIDI-Engine can support up to 32-channel musical synthesizing functions. The 4-bit QSPI interface can rapidly read the MIDI tones from an external SPI Flash memory and the 16-bit high performance D/A converter provides a stereophonic output. A standard I2S interface can connect with external audio CODECs.
Additionally, the device also contains a 16-channel 12-bit A/D converter and a USB 2.0 Full Speed interface. Several standard communication interfaces, including USART, UART, SPI and I2C interfaces are fully integrated to increase the application flexibility.
The HT32F0006 is suitable for voice/music related applications and with its high degree of functional integration greatly simplifies circuit design. The device supports an operating voltage ranging from 2.0V to 3.6V and is supplied in 48/64-pin LQFP package types, which can meet a variety of application requirements. The device also supports an operating temperature of -40°C~85°C, which meets with the industrial specifications.
