HOLTEK New BC2302A/B Sub-1GHz Superheterodyne OOK RF Receiver ICs
Published: Jan 22,2019354 Read
Holtek announced the release of its new Sub-1GHz Superheterodyne OOK high performance RF receiver ICs, the BC2302A and BC2302B. The BC2302A, which operates in the 300MHz~450MHz bands, and the BC2302B, which operates in the Sub-1GHz bands of 300MHz~935MHz, both operate within the ISM license-free frequency bands. The RF characteristics of the devices are also compliant with ETSI/FCC specifications. Other features include requiring a minimal number of antenna matching components and excellent stability make these devices suitable for use in mains or battery powered wireless receiver products such as RF wireless ceiling lamps, wireless doorbells, rolling doors, smart home appliances and many other wireless products.
HOLTEK New HT32F67233 Sub-1GHz GFSK Transceiver Arm Cortex -M0+ MCU
Holtek announces the release of its new wireless communication dedicated MCU, an Arm Cortex-M0+ core Sub-1GHz GFSK transceiver, the HT32F67233...
HOLTEK New BC66F2143 Sub-1GHz RF Transmitter MCU
Holtek announces the release of its new Sub-1GHz RF OOK/FSK Transmitter Flash MCU, the BC66F2143. This new device, which can operate in the license-free ISM bands...
The devices have a wide operating voltage range of 2.5V~5.5V, low receiving current of 3.2mA in the 433MHz frequency band, a high receiving sensitivity of up to -110dBm at a 25ksps data rate, a maximum transmission rate of 25ksps and a low power down current of less than 1µA.
The devices can directly work to receive RF independently after a power on reset operation without other configurations or can be connected to an MCU via their integrated I2C interface to configure certain parameters such as the frequency band selection, before activating the RF receiver. The devices support a 16MHz external crystal oscillator and have integrated auto calibration and auto gain control functions for auto compensation and adaptation to the operating environment. The devices have an operating temperature of -40°C~85°C and are supplied in a small 8-pin SOP-EP package type which will meet the requirements of low profile product and receiver module designs.
