HOLTEK’s New HT66F0021/HT66F0031/HT66F0041 Cost-Effective MCUs

Published: Jun 20,2019

3243 Read

Holtek announced the release of three new high performance/cost ratio small package Flash MCUs, the HT66F0021, HT66F0031 and HT66F0041. These three new devices are especially designed for applications such as small household appliances but of course could see excellent use in other application areas.

More on This

HOLTEK New HT66F0184 Streamlined A/D Flash MCU

Holtek announced the release of a new device addition to its A/D Flash MCU with EEPROM range, the HT66F0184. This is provided as a streamlined product to the HT66F0185 device...

HOLTEK New HT45F5Q-3 Charger MCU

Within the charger product application area, Holtek announced the release of its new charger application specific MCU, the HT45F5Q-3...

The HT66F0021 and HT66F0031 devices include 1K×14 bits of Flash Program Memory while the HT66F0041 includes 2K×14 bits of Flash Program Memory. These devices all have 64 bytes of SRAM, 32×14 bits of emulated EEPROM, an operating voltage of 1.8V~5.5V, a fast 4-channel 10-bit resolution A/D Converter, a Timer Module and an 8-bit PWM output. Two fully internal oscillator options are provided, one is an 8MHz HIRC and the other is a 32kHz LIRC. The integrated high resolution HIRC oscillation circuit has a resolution of ±0.5% under the conditions of fixed voltage and fixed temperature while the LIRC has a resolution of ±1%.

With regards to packaging, the HT66F0021 is supplied in an 8-pin SOP package type, the HT66F0031 is supplied in a 16-pin NSOP package type while the HT66F0041 is supplied in 16-pin/20-pin NSOP and 20-pin SSOP package types. Using these minimal size package types makes these devices very suitable for use in small profile household appliances.
