ST Teams with Arrow to Provide e-Fuel-Injection Reference Design Compliant

Published: Aug 16,2019

2367 Read

To help the automotive industry meet the upcoming emissions regulations for single- and twin-cylinder gasoline engines, STMicroelectronics, with Arrow Electronics, has released a complete reference design ECU (Electronic Control Unit) for electronic fuel-injection (EFI).

More on This

STM to Supply Advanced SiC Power Electronics to Renault-Nissan-Mitsubishi for Next-Gen EVs

STMicroelectronics has been chosen to supply high-efficiency silicon-carbide (SiC) power electronics by Renault-Nissan-M...

New Discovery Kits and Firmware from STMicroelectronics Kickstart STM32G4

STMicroelectronics has extended support for STM32G4 microcontrollers, delivering digital-power and motor-control Discove...

The SPC5-L9177A-K02 ECU Reference Design targets small engines for motorcycles, scooters, and three wheelers, which must satisfy upcoming Euro 5, Bharat Stage VI (BSVI), and China IV and beyond, and can also address generators, nautical engines, and agricultural engines equipped with EFI ECU.

The reference design key components are ST’s SPC572L Line 32-bit Power Architecture automotive-powertrain microcontroller and L9177A high-integration IC hosting power supplies, interfaces and load actuators, which are specifically designed for the application and market needs. ST’s STGD18N40 IGBT and L9616 CAN interface IC are also included.

The board is ready for customers to develop their applications, coming with a full ecosystem, including SPC5Studio Integrated Development Environment (IDE) which includes low-level drivers, a Generic Timer Module (GTM) configurator for the SPC572L Line, and powertrain libraries for engine crank position sensor and actuations. To overcome the complex challenges associated with electronic fuel injection, a basic application software developed in association with ST Partner eMoticom helps users start and manage a single-cylinder engine.
