Toshiba Launches Compact, Low Power, High Resolution Micro-stepping Motor Driver IC

Published: Feb 06,2020

318 Read

Toshiba has launched “TC78H670FTG,” the latest addition to its line-up of micro-stepping motor driver ICs. The new IC has a maximum rating of 18V/2.0A and can drive motors with a wide range of operating voltages. Mass production starts today.

More on This

Toshiba Launches Ultra-Low Current Consumption CMOS Operational Amplifier

Toshiba has added “TC75S102F,” a new CMOS operational amplifier featuring industry-leading ultra-low current consumption to its lineup...

Toshiba Launches Photorelays in New Package for High-density Mounting

Toshiba has launched three photorelays, TLP3480, TLP3481 and TLP3482 in P-SON4, a new package with a significantly smaller mounting area than Toshiba’s SOP packages...

The new IC can drive a 128 micro-stepping motor with a power supply ranging from 2.5V to 16V. Its wide range of applications includes USB-powered, battery-powered, and standard 9-12V system devices, and it can also be used with a 1.8V interface, allowing connection to various hosts and microcontrollers.

Toshiba’s newest DMOS process ensures that TC78H670FTG realizes excellent figure-of-merit low ON resistance. The process also contributes to the IC’s ultra-low standby current. The IC is housed in a compact QFN16 package and eliminates use of a current sense resistor by incorporating a current detection part that contributes to lower cost, a smaller component footprint, and PCB routing space savings.
