Battery technology advancements and government regulations have resulted in a growing number of new electric vehicles around the world. But vehicle makers still need more charging stations to make it easier for drivers to charge their vehicles.

The new reference design uses TI's SimpleLink Wi-Fi wireless microcontroller (MCU) technology that allows design engineers to create stations that intelligently charge at non-peak times or detect and communicate when a charging station is available.

One barrier to widespread EV charging station adoption is the amount of time it takes to charge a vehicle. The reference design supports Level 1 charging, which is compatible with household outlets, as well as Level 2 EV charging, which helps vehicle owners tap into higher current (15A to 30A and higher) connections available in commercial office buildings. Level 2 chargers typically take up to eight hours to fully charge the vehicle if the owner wants to plug it in while at work.

Features:

• Level 1 and Level 2 charge operation.

• Wi-Fi connectivity support from any smartphone, tablet, computer or smartTV thanks to TI's SimpleLink Wi-Fi technology.

• Power delivery up to 30 A, but expandable by using larger relays.

• Expandable to support other applications such as payment, authentication and home automation design innovation.
