The A5100-A is the first release within Maestro’s new line of GNSS receivers. It achieves unprecedented accuracy with quad-constellation support, up to 30 per cent faster Time-To-First-Fix (TTFF), and up to 20 per cent lower power consumption using CSR’s TricklePower and Push-to-Fix (PtF) modes.

The module also accelerates customer time to market and reduces development risks by integrating a number of features including, TCXO, SAW filter, RTC, antenna control mechanism, and flash memory for future-proof upgrades, as well as, offering a drop-in replacement capability for Maestro’s previous SiRFstar4 generation modules. The castellated edge form factor also enables simpler manufacturing and reduces assembly cost.

“Maestro Wireless has worked closely with CSR for many years to design and commercialise highly accurate and reliable location products,” said Anthony Murray, Senior Vice President, Business Group at CSR.

“But to win in today’s highly competitive consumer electronics market performance isn’t enough. That’s why we’ve worked with Maestro Wireless to develop a solution that excels in a range of performance metrics but also offers the small form factor essential for today’s compact devices and is highly integrated to help them get to market fast.”

Supporting all currently deployed GNSS, the A5100-A acquires and tracks all visible GPS, GLONASS, QZSS, and SBAS satellites. Concurrent GNSS performance enables the A5100-A to choose the best satellites from different constellations and deliver optimal location information. Immediate benefits are better coverage, enhanced stability and accuracy in difficult environments, such as urban canyons, and stronger resilience to multipath and signal jamming. This ensures consumers maintain a position fix whether they’re in the middle of a busy city or in a remote rural location.

“The A5100-A is perfect for customers designing highly integrated products that need uncompromising performance but are pressured by the speed required to go-to market and lack of development resources,” said Olivier Bernard, EVP of Business Development at Maestro.

“By combining low power consumption with high sensitivity, high jamming immunity and concurrent GNSS operation, and with its drop in upgrade path to the A2200-A, the A5100-A creates a fast and convenient route to the latest GNSS offering in the marketplace, to meet these needs quickly.”

Features:

- Direct to Battery connectivity

- Low Power technology

- InstantFix Extended Ephemeris (EE)
