LucidShape's new Visualize Module delivers high-speed photorealistic images of an automotive lighting system's lit appearance, which demonstrate luminance effects when light sources in a model are illuminated. Because the Visualize Module depicts all interactions between system geometry and light sources, it provides designers with a physically correct diagnostic tool for evaluating how a lighting system will be perceived by the human eye.

This is particularly important for evaluating automotive components such as turn signals and brake lights. The Visualize Module is a fast, reliable engineering tool that enables designers to perform design checks and make improvements early and often in the product development process.

The Ray Data Viewer now provided with LucidShape creates illuminance images based on ray data sources. This allows designers to quickly preview the lit appearance and structure of vendor light sources before incorporating them into their models. Sources can be viewed from various angles using a camera positioning capability.

The new Light Pipe Tool simplifies and speeds the creation of complete light pipe designs by allowing prism bands, which model sheets of prismatic microstructures, to be created in conjunction with light pipe surfaces in LucidShape. With this tool, the light pipe surface is automatically fit to the prism band and merged into a single new shape, producing a seamless, optically accurate light guide.

LucidShape's material library, which provides a wide array of surface material and bulk volume media, has been expanded to include measured BSDF models from Synopsys' LightTools illumination design software. The new measured BSDF data delivers unsurpassed accuracy for modeling surface scattering for materials commonly used in automotive lighting and can be expanded and customized by designers according to their unique requirements.

Features:

－ Supports environment sources for the integration of 360-degree, high-dynamic range (HDR) photographic environments into photorealistic visualizations. Includes all physical and optical properties for an immersive, accurate rendering of a lighting scene.

－ Combines LucidShape's luminance camera and backward ray tracing to perform rapid, high-accuracy luminance calculations and generate photorealistic images at multiple angles and viewing directions.

－ Harnesses LucidShape's GPUtrace solution, which uses graphics processing unit (GPU) computing to accelerate illumination simulations by orders of magnitude compared to multithreading capabilities. The speed of the Visualize Module's simulations gives designers the flexibility to rapidly evaluate their models at any point in the design process.
