The LAN9252 supports traditional Host Bus and SPI/SQI communication, along with standalone digital I/O interfaces, providing system designers the flexibility to select from a wide range of microcontrollers when implementing the real-time EtherCAT communications standard. Additionally, the LAN9252 reduces system complexity and cost for developers using EtherCAT in factory-automation, process-control, motor/motion-control and Internet of Things (IoT) industrial-Ethernet applications.

“Microchip’s history as a supplier supporting the very long product life cycles in the industrial market, combined with our leading-edge Ethernet devices, ensures customers have a reliable partner,” said Mitch Obolsky, VP of Microchip’s USB and Networking Group. “Adding EtherCAT technology, with its expanding market share, is a significant addition to our industry-leading Ethernet portfolio. The LAN9252 provides our customers with ease-of-use and configuration flexibility, taking communication and connectivity in embedded industrial designs to the next level.”

Fully compliant with the EtherCAT standard and interoperable with all EtherCAT systems, the LAN9252 EtherCAT slave controller includes 4 Kbytes of Dual-Port RAM (DPRAM) and three Fieldbus Memory Management Units (FMMUs). The LAN9252 also features cable diagnostics support that allows field service technicians to rapidly and effectively diagnose line faults and provides for fiber connectivity. This EtherCAT slave controller is available in commercial, industrial and extended industrial temperature ranges, in low pin count and small body size QFN and QFP-EP packages.

To enable development with the LAN9252, two Microchip evaluation boards supporting various system architectures were also announced today. These hardware systems demonstrate how to interface to the LAN9252 through basic input/output connections, or to microcontrollers such as the 32-bit PIC32MX family via serial communications. A Software Development Kit (SDK) is also available today, which further enables developers to immediately start device evaluation and begin building solutions for their applications, allowing them to quickly familiarize themselves with features of the LAN9252.
