Acute Releases USB PD 2.0 Bus Decode for Logic Analyzer
Published: May 06,2016335 Read
Acute Technology Inc. provides the mixture for the quick measurement of USB PD 2.0, just connect the Configuration Channel (CC1 or CC2) and Ground pins with Logic analyzer.
Acute Technology has officially released the USB PD (Power Delivery) 2.0 bus decode. USB PD 2.0 protocol is applied to the devices which have USB type-c connector in notebook, tablet PC, mobile phone, power bank, etc. It can be a power supply or recharging.
Acute Technology Launches the 100MHz Bandwidth High-voltage Differential Probes
Acute announced its new 100MHz bandwidth high-voltage differential probes: the ADP1100 and the ADP2100. These probes with good CMRR and low noise floor performance...
Features:
- Measure the Configuration Channel (CC1 / CC2)
- Bus decode information
• Monitor the status of voltage and current by the message of Power Negotiation
• Monitor the switch of alternate mode
• View the VDM (Vendor Defined Message)
• View the 4b / 5b value
• View the message between host (Source) and device (Sink)
• Monitor the switch of upstream/downstream
• Bit rate automatically detect
