N-channel MOSFET Driver ICs in Industry-Leading Small Package

Published: Sep 28,2017

350 Read

Toshiba Electronic Devices & Storage Corporation today announced the launch of “TCK401G” (active-high) and “TCK402G” (active-low), N-channel MOSFET drivers that support an input voltage of up to 28V, making them suitable for quick-charging and other applications requiring high current supply. Volume shipment of the new MOSFET driver ICs starts today.

More on This

Toshiba Memory to Further Invest in Production Equipment for Fab 6 at Yokkaichi Operations

Toshiba Corporation today announced that its board of directors has approved a further investment by Toshiba Memory Corporation (TMC)...

Toshiba Develops Next-Generation Lithium-ion Battery with New Anode Material

Toshiba Corporation today announced the development of its next-generation SCiB, which uses a new material to double the capacity of the battery anode...

The new TCK401G and TCK402G have various built-in functions, including overvoltage protection, inrush current reducing and auto output discharge, but are still housed in the industry-leading small WCSP6E package, measuring 0.8 mm × 1.2 mm × 0.55 mm (typical).

A high-efficiency power supply circuit can be realized by using one of the drivers with an external N-channel MOSFET that has a maximum voltage rating and on-resistance suitable for the target application. For example, the combination of a new MOSFET driver and the low-on-resistance SSM6K513NU MOSFET is suitable for mobile and consumer applications, as it makes it possible to build a 100-W-class power supply circuit in a small space.
