Renesas Announces New Scalable Digital Controllers

Published: Jul 19,2018

1498 Read

Renesas Electronics announced two new PMBus compliant, fully digital DC/DC controllers that provide single output point-of-load (POL) conversions for FPGAs, DSPs, ASICs, network processors and general purpose system rails. The ISL68300 with integrated MOSFET drivers and ISL68301 with PWM output simplify designing power supplies for data center, wired and wireless communications, and factory automation equipment. The ISL68300 can drive discrete external MOSFETs directly, while the ISL68301 pairs with Renesas’ smart power stages or DrMOS power stages to create a complete voltage regulator solution.

More on This

Renesas Introduces Ultra-Small RX651 32-Bit MCUs for IoT Modules and Space-Constrained Edge Devices

Renesas Electronics announced four new RX651 32-bit microcontrollers (MCUs) supplied in ultra-small 64-pin BGA and LQFP packages...

Renesas Electronics Announces Industry’s First USB-C Combo Buck-Boost Battery Charger

Renesas Electronics Corporation introduced the industry’s first USB-C buck-boost battery charger to support both Narro...

The ISL68300 and ISL68301 digital controllers feature a high-speed current share bus that parallels up to eight controllers in an 8-phase 240A+ current share configuration. Both controllers implement Renesas’ digital ChargeMode control modulation, which responds to load transients in a single switching cycle, and provides an inherently stable control loop without requiring external compensation. This modulation architecture significantly reduces output capacitor requirements and minimizes Vout undershoot and overshoot.

“The scalability of the ISL68300 and ISL68301 single output digital controllers provide industry leading performance and support a wide range of load currents,” said Mark Downing, Vice President, Core Power Solutions Division, Renesas Electronics Corporation. “The new digital controllers complement our award-winning digital dual-output multiphase controllers, giving customers everything they need to power all the rails in their next-generation systems.”

Engineers can use the PowerNavigator GUI with the ISL68300 and ISL68301 to simplify power supply setup, sequencing, configuration and monitoring, including all device parameters and telemetry. Full schematic designs are completed in minutes, and the GUI with PMBus makes it easy to control the entire design and change features without soldering components or rework.

In a typical FPGA power supply, the ISL68300 and ISL68301 digital controllers provide single output 10A to 40A+ for auxiliary rails, DDR memory, and system rails. The companion Renesas digital multiphase controllers use smart power stages to provide dual output 15A to 70A, or higher core power.
