Rugged, Reliable Ultra-fast 1400V IGBT Optimized for Induction Heating and Soft Switching Applicatio

Published: Mar 11,2014

3302 Read

International Rectifier(IR) today introduced a rugged, reliable ultra-fast 1400V Trench Insulated Gate Bipolar Transistor (IGBT) optimized for soft switching applications including induction cooktops and microwave ovens.

More on This

IR’s Battery Protection MOSFETs Offers Cost-Effective, Flexible Solution for Mobile

International Rectifier, IR, announced the introduction of an extensive portfolio of devices featuring IR’s latest low...

StrongIRFET Family with New Surface Mount 75V MOSFETs Featuring Ultra-low Rds

International Rectifier(IR) announced the expansion of its StrongIRFET MOSFET portfolio to include 75V devices for a wid...

Co-packaged with an ultra-low forward voltage diode, the IRG7PK35UD1PbF utilizes IR’s Gen7 thin-wafer trench technology to deliver extremely low VCE(ON) and ultra-fast switching to offer superior conduction and switching losses for high system efficiency in induction heating applications. Expanding the voltage range of the device to 1400V enables the design of higher power single-ended parallel resonant power converters and offers additional guard band for more robust designs.

“Leveraging IR’s 1400V Trench Gate, Field Stop technology, the IRG7PK35UD1PbF is optimized for lowest conduction and switching losses and enhanced system reliability in induction heating and soft switching applications,” said Llewellyn Vaughan-Edmunds, IGBT Product Marketing Manager, IR’s Energy Saving Products Business Unit.

The IRG7PK35UD1PbF expands IR’s proven family of IGBTs for soft-switching applications to 1400V, extending the power range of induction heating systems. IR’s focus on power applications allows for optimization of devices to meet the technical requirements of various power systems.

Features:

Low VCE(ON), ultra-low VF, and turn-off soft switching losses

Positive VCE (ON) temperature coefficient and tight distribution of parameters

Lead-free, RoHS compliant
