Industry’s smallest 15-A, multiphase DC/DC converter for personal electronics
Published: Mar 14,2014389 Read
Texas Instruments (TI) introduced the industry’s smallest 15-amp, multiphase step-down converter that meets power requirements of leading-edge quad-core processors and octa-core processors to extend battery run-time in smartphones and tablets.
Smallest Data Converters Deliver High Integration and Performance
Texas Instruments (TI) introduced four tiny precision data converters, each the industry’s smallest in its class. The ...
TI Introduces a New Family of LED Drivers with 12-bit PWM, 29-kHz Dimming Frequency
First 12-bit, 29-kHz RGB LED Driver Family Enables Vivid Color and Seamless Animation with Zero Audible Noise Texas I...
The new LP8755 achieves a 70 mm2 total solution size, and supports up to 15 A from a 2.5-V to 5-V input with 90 percent efficiency.
The LP8755 converter with integrated FETs uses two I2C interfaces to manage dynamic voltage scaling, and features an automatic phase-adding and shedding technique to maintain the highest level of efficiency across a wide output current. During light load operation, the regulator enters a low-power mode as low as 10 uA (Iq) per converter core for maximum efficiency.
Features：
－ Six High-Efficiency Step-Down DC/DC Converter Cores:
－ I2C-Compatible Interface which Supports
Standard (100 kHz), Fast (400 kHz), and High-Speed
(3.4 MHz) Modes
－ Four Pin-Selectable I2C Addresses
－ Interrupt Function with Programmable Masking
－ Output Short-Circuit and Input Over-voltage Protection
－ Spread Spectrum for EMI Reduction
－ Over-Temperature Protection (OTP)
－ Under-Voltage Lock-out (UVLO)
－ 49-Bump 0.4 mm Pitch DSBGA Package, 2.99 mm × 2.85 mm
