High Energy-Measurement Accuracy with Integrated Single-Phase Metering SoC
Published: Apr 15,201447 Read
Using the ZON M3 (MAX71315) single-phase electricity meter SoC from Maxim Integrated Products, Inc., engineers now have a highly accurate, low-cost design system for e-meters and solid-state meters.
Analog’s $20bn Maxim Deal Another Example of Semiconductor Sector Shakeout, says GlobalData
The global semiconductor industry has too much capacity, too many players and has had declining revenues since the end of 2018...
Maxim Announces Industry's First Remote Tuner Solution with Single Hardware Platform
Using the remote tuner solution from Maxim Integrated Products, Inc., designers can significantly simplify the head unit design of a vehicle and reduce cables...
Superior metering metrology is essential for accurate monitoring and billing. Additionally, meter manufacturers must consider cost in their designs, as millions of meters are being deployed throughout the globe.
The ZON M3 energy-meter solution integrates four 24-bit ADCs for 4-channel data collection and ±0.1% measurement accuracy over 5000:1 dynamic range.
A 32-bit metrology compute engine (CE) ensures high-accuracy processing of all collected data. Its two touch-switch inputs eliminate mechanical switches and improve user experience, and its infrared (IR) communications interface eliminates the typical extra IR receiver module. All the high integration reduces cost and improves user experience.
Features:
• Four Independent Metrology Channels
• 0.1% Accuracy Over 5000:1 Current Range with Integrated Metrology ADCs
• Two Remote ADC Interfaces
• Support Current Transformers, Rogowski Coils, and Shunts
• Four Pulse Outputs from the CE
• Digital Temperature Compensation for Metrology
• 45Hz to 65Hz Line Frequency Range with the Same Calibration
• Phase Compensation (±10°)
• 256kB Flash, 12kB SRAM (MAX71315)
• 128kB Flash, 12kB SRAM (MAX71314)
• Single-Cycle 32 x 32 + 64 Multiply-Accumulate Unit
• Low-Power 5ksps ADC for Environmental Monitoring
• RTC with Temperature Compensation
• On-Chip Digital Temperature Sensor
• LCD Controller Supporting Up to Eight Common Planes
• Two PWM Relay Control Channels with Programmable Frequency, Duty Cycle, and Ramp Time
• Two Touch Switch Inputs
• 1.75µA Sleep Mode
• SPI (Master and Slave), Master I2C, 4 x UARTs
• Two Smart Card Ports
• 38kHz IR Encoder/Decoder
• Up to 10 MIPS (at 10MHz)
• 100-Pin LQFP
