New Qualified IP Blocks on 180 nm Process to Reduced Time to Market

Published: May 07,2014

33 Read

ON Semiconductor has announced the availability of new qualified intellectual property (IP) on its proprietary ONC18 180 nanometer (nm) process technology. The newly qualified circuit blocks will help ON Semiconductor’s foundry (GDS2) interface customers minimize the risk of the need for silicon re-spins and therefore help reduce development costs and shorten time-to-market for new designs.

More on This

New Ultra-Low Power Precision Operational Amplifiers for IoT Applications

ON Semiconductor has introduced a family of affordable, precision CMOS operational amplifiers (op amps) that deliver zer...

New 2.1 Megapixel CMOS Image Sensor Delivers 1080p HDR Video for Security Cameras

ON Semiconductor has introduced its latest high performance CMOS image sensor targeted for use in advanced video security cameras...

Through its Custom Foundry Business Unit, ON Semiconductor continues to offer new blocks of IP qualified in their proprietary processes developed by various external vendors including Micro Oscillator Inc., Senseeker Engineering Inc., and Silicon Storage Technology, Inc. The ten (10) new IP blocks that have most recently been qualified, provide functions that range from small-pitch column-parallel ADC and cryogenic-compatible LVDS drivers to ultra-low power oscillator and very-small footprint OTP memory.

These IP blocks are applicable and beneficial to a wide range of customer end-markets including military/aerospace, medical, consumer, computing, communications, and automotive. In addition to supporting the work of ASIC designers in these sectors, the availability of qualified IP will also help design houses achieve reduced costs and enhanced schedule accuracy in quotations to end customers.

“Working to qualify mixed-signal IP on our leading semiconductor processes is a key part of our strategy to help designers across a wide and diverse range of industry sectors and end applications to shorten time-to-market and reduce development costs for their new products,” said Vince Hopkin, Vice President, Mil/Aero, Digital, Custom Foundry, IPD and Image Sensor Products Division at ON Semiconductor.

“Using qualified IP can mitigate the need for costly design re-spins that are sometimes needed to address unforeseen circuit block performance problems or characteristics during the development process and that can critically delay launching products to market.”
