HOLTEK New HT32F67233 Sub-1GHz GFSK Transceiver Arm Cortex -M0+ MCU

Published: Jul 27,2023

4461 Read

Holtek announces the release of its new wireless communication dedicated MCU, an Arm Cortex-M0+ core Sub-1GHz GFSK transceiver, the HT32F67233. The device operates in the 315/433/470/868/915MHz license-free ISM Bands and is suitable for wireless bidirectional transmission applications such as in smart homes, security products, industrial/agricultural automation, data acquisition and recording, etc.

More on This

HOLTEK New BC66F2143 Sub-1GHz RF Transmitter MCU

Holtek announces the release of its new Sub-1GHz RF OOK/FSK Transmitter Flash MCU, the BC66F2143. This new device, which can operate in the license-free ISM bands...

HOLTEK New HT6xL25x0A Low Power A/D MCU

Holtek announced the release of its new Low Power MCUs, the A/D Flash HT66L2540A/HT66L2550A MCUs and the A/D Flash with LCD driver HT67L2540A/HT67L2550A MCUs...

The device has an operating frequency of up to 40MHz, contains a 32KB Flash memory, a 4 KB SRAM and provides a maximum RF transmitting power of +20dBm. Its receiving current can be as low as 5.8mA at 433MHz. It supports both OOK and GFSK modulation and has a transmission rate of up to 250Kbps. The device also includes an Auto-Transmit-Receive (ATR) function.

With regard to interfaces, it contains 21 GPIO pins and multiple communication interfaces, including UART, USART, I²C and SPI type interfaces. It has an operating voltage range of 2.0V~3.6V and is supplied in a 46-pin QFP package type.

To assist users with their HT32F67233 applications, the Holtek RF service teams are available to help customers with the rapid development of their various IoT applications.
