Imec and Crystal Solar Demonstrate 22.5% nPERT Si Solar Cells

Published: Apr 14,2016

Nanoelectronics research center imec and Crystal Solar, a pioneer in direct wafer growing technologies for the next generation of solar photovoltaic products, today announced that they have achieved a 22.5 percent cell efficiency (certified by FhG ISE CalLab) with nPERT silicon (Si) solar cells manufactured on 6-inch mono-crystalline epitaxially grown kerfless wafers.

More on This

Imec’s Virtual Fab Underpins Strategies to Reduce the Carbon Footprint of Lithography and Etch

At the 2023 Advanced Lithography + Patterning Conference, imec presents a quantitative assessment of the environmental impact of patterning in advanced IC manufacturing...

Swave, a new Imec and VUB Spin-off, Raises €7M to Deliver True AR/VR Experiences

Swave Photonics, an innovator in Holographic eXtended Reality (HXR) technology to bring the metaverse to life, today announced a €7 million seed round...

Crystal Solar’s breakthrough manufacturing technology called Direct Gas to WaferTM enables direct conversion of feedstock gas to mono crystalline silicon wafers by high throughput epitaxial growth.

By skipping the polysilicon, ingoting and the wire-sawing steps altogether, this approach not only results in lowest cost/watt for the wafers but also significantly reduces the capital required to set up a manufacturing plant. Furthermore, this process enables the growth of high quality p-n junctions in-situ which reduces cell making steps while increasing the efficiency.

Imec has adapted its highly efficient nPERT Si solar cell process to align with the properties of Crystal Solar’s kerfless wafers. The 156x156mm2 cells were fabricated on 160 to 180 um thick grown n-type wafers with built-in rear p+ emitter.

Imec’s n-PERT process included a selective front surface field realized by laser doping, advanced emitter surface passivation by Al2O3 and Ni/Cu plated contacts.

The novel process using all industrially available processing steps resulted in record efficiencies for homojunction large area solar cells of 22.5 percent and a record Voc of 700mV. This high Voc illustrates the high quality of the wafers and the built-in junction.

Jozef Szlufcik, PV Department Director at imec: “We are extremely happy to have achieved such high conversion efficiencies on nPERT solar cells processed from kerfless wafers using imec’s pre-pilot industrial silicon PV manufacturing line.

The combination of our advanced cell process and the innovative wafer manufacturing technique of Crystal Solar, is paving the way for manufacturing of highly efficient solar cells at substantially lower cost and will be disruptive for the complete solar manufacturing value chain.”

“We are pleased to see such a high conversion efficiency on our epitaxially grown n-type wafers with built in boron doped junctions”, said T.S. Ravi, CEO of Crystal Solar.

“This approach represents a new paradigm in cell manufacturing with its unique ability to bypass significant steps in both wafer and cell manufacturing thereby dramatically reducing the capex and the overall cost per watt. We expect to achieve >23% efficiencies with imec’s PERT technology in the very near future”, Mr. Ravi concluded.
