New BH66F2650/2660 Flash MCUs for eight-electrode AC Body Fat Scale Applications

Published: Sep 11,2017

333 Read

Following the successful previous release of its four-electrode AC body fat scale, HT45F75/77 devices, Holtek announced the release of its new eight-electrode AC body fat scale Flash MCUs, the BH66F2650/60.

More on This

HOLTEK New HT45B0016 Wireless Charger Transmitter’s Power Stage

Directly aimed at the wireless charger transmitter application area, Holtek presently announces the release of its new two-in-one half-bridge power device, the HT45B0016...

HOLTEK New BS83B24C/BS83C40C High Key Count High Anti-interference Touch MCUs

Holtek announced the release of a new generation of Touch Flash MCUs, the BS83xxxC series. In addition to including all the advantages of the already released BS83BxxA series...

Eight-electrode body fat scales are used to measure body fat including legs, arms and torsos measurements which can reflect the body condition. These devices support both AC body fat and weight measurements, which are more accurate means of measurement when compared with traditional DC fat scales.

With regard to how the measurement data is displayed, the body fat and weight information can be transmitted to a mobile phone by using the internal SPI/I2C/UART serial interfaces and an external bluetooth module. The data can also be displayed on an LED Panel using the internal LED driver.

The devices provide an AC body fat measurement circuit, an LED driver, LDO, PGA and a 24-bit Delta Sigma A/D Converter. With this high level of functional integration, the required number of external components is greatly reduced which will result in reduced manufacturing costs and improved productivity.

The devices include 8K/16K words of Flash Program Memory, 256/1024 bytes of Data Memory, 64/256 bytes of True Data EEPROM, IAP (In-Application Programming) function, Multiplication Division Unit and Timer Modules. With regard to packaging, the devices are supplied in 48-pin LQFP package types.

To support these new devices, Holtek supplies a full suite of excellent hardware and software development tools including the HT-IDE3000 and ICE (In-Circuit-Emulator) which include trace analysis features, breakpoint setup as well as a host of other functions. The Holtek's e-WriterPro also provides a means of ICP (In-Circuit Programming) to allow for fast program updates during development and ensure developers have their designs up and running in the shortest time possible
