HOLTEK New BH67F2752 Infrared Thermometer MCU

Published: Feb 21,2019

314 Read

Holtek wishes to announce the release of its new Infrared Thermometer MCU, the BH67F2752. The device’s fully integrated Thermopile AFE and LCD driver make the device suitable for use in LCD type Infrared Thermometer products, such as ear thermometers, forehead thermometers and infrared thermometers etc.

More on This

HOLTEK New HT66F0184 Streamlined A/D Flash MCU

Holtek announced the release of a new device addition to its A/D Flash MCU with EEPROM range, the HT66F0184. This is provided as a streamlined product to the HT66F0185 device...

HOLTEK New HT45F5Q-3 Charger MCU

Within the charger product application area, Holtek announced the release of its new charger application specific MCU, the HT45F5Q-3...

The device includes a fully integrated Thermopile AFE circuit, which includes an OPA, LDO, PGA and a 24-bit Delta Sigma A/D Converter. The 128 bytes of True EEPROM Memory can be automatically calibrated during production by software and the UART/SPI interfaces can be used for connecting to peripheral devices such as Bluetooth etc.

Due to these internal features, the required number of external components is greatly reduced which will result in reduced manufacturing costs. As for system resources, the device includes 8K words of Flash Program Memory, 384 bytes of Data Memory and a Timer Module.

The device is supplied in both 48-pin and 64-pin LQFP package types. The hardware development tool is known as the e-Link which works together with an OCDS (On Chip Debug Support) architecture BH67V2752, which can provide users with rapid development and simulation to achieve a greatly reduced time to market.
