HOLTEK New HT67F2432 High Accuracy HIRC MCU

Published: Dec 02,2019

191 Read

Holtek announced the release of a new addition to its LCD Display Flash MCU range with its new HT67F2432. The device includes a high accuracy, high frequency 4MHz RC oscillator and an LCD driver which supports up to 4COM×20SEG LCD display sizes, making the device suitable for high accurate signal output and LCD display requirement product applications, such as bath heater remote controls, RF remote controls, LCD simple remote controls, LCD timers, fish tank automatic feeders, etc.

More on This

HOLTEK New Arm Cortex-M0+ Based 32-bit Flash MCU Series HT32F573xx

Holtek announced the release of its new generation Arm Cortex-M0+ Microcontroller device series, the HT32F57331/57341/57342/57352 series...

HOLTEK New BS83A04C Low Power Enhanced Touch MCU

Holtek announced the release of a new generation high noise immunity Enhanced Touch I/O Flash MCU, the BS83A04C. This device has low power characteristics...

With regards to the main system resources, the device has a Flash program memory capacity of 2K×16, a data memory capacity of 128×8, a True EEPROM memory capacity of 32×16, a 5 channel 10-bit A/D converter and an operating voltage of 1.8V~5.5V. Under the temperature condition range of -10℃to 50℃and an operating voltage range of 1.8V to 3.6V, the internal integrated high accuracy high frequency 4MHz RC oscillator has a tolerance of less than ± 0.45%.

The device 9-bit carrier counter can be used to generate infrared signals with specific specifications and the UART function can be used to communicate with external RF modules. The device is supplied in 24-pin SOP/SSOP and 28-pin SOP/SSOP package types.
