New 315M/433MHz RF Transmitter MCU Supplied in a 16-pin NSOP

Published: Oct 08,2014

23 Read

Holtek wishes to announce the release of its new low-cost RF Transmitter MCU device, the BC48R2020. The device is supplied in a 16-pin NSOP package type whose pins are compatible with its predecessor product, the HT48R01T3.

More on This

HOLTEK New HT32F61730/741 Li-Battery Management MCUs

Holtek announced the release of two new Li-Battery management MCUs, the HT32F61730 and HT32F61741. Compared with the second generation HT32F61630 and HT32F61641 devices...

HOLTEK New HT45R6Q-2/HT45R6Q-3 Battery Charger OTP MCU

Holtek has further expanded its range of battery charger OTP MCUs with the present release of two new devices, the HT45R6Q-2 and HT45R6Q-3...

The device meets with full industrial specification operating temperature requirements of -40°C ~ 85°C as well as possessing excellent noise immunity characteristics. Regarding its RF capabilities, the RF transmitter uses ASK modulation in the 300MHz ~ 450MHz RF transmission frequency range with data rates of higher than 10Kbps.

With a 3.5V operating voltage, the transmission power can reach a maximum safety specified level of 10dBm. By including a data tracking function, transmission is implemented only when data is being sent out without requiring additional MCU control, resulting in extremely low system power consumption.

The device includes a fully integrated 8MHz RC oscillator for MCU system operation. The RF transmission frequency is determined by an external crystal oscillator. Additional device special features include its small package outline and easy to use functions.

With only a few external passive components required to implement a full RF transmitter application solution, this low cost, small package, high efficiency wireless MCU device will find excellent use in a huge range of wireless applications.

As one would expect, Holtek of course supplies a full suite of hardware and software development tools. Known as the HT-IDE3000, this development system includes real time emulation with its In-Circuit-Emulator, full trace analysis functions, breakpoint functions etc. With Holtek’s RF engineering support team ready to provide customer technology support, users are assured of having their wireless designs up and running in as short a time as possible.
