HOLTEK New Touch Key ICs for Household Appliance Applications
Published: Dec 15,20142232 Read
The release of the new BS812A-1, BS8112A-3 and BS8116A-3 devices adds three new additions to Holtek’s standard touch key peripheral IC series. These new touch switch devices allow human body contact to be detected using external touch keys while internal circuitry provides automatic calibration according to environmental changes, to enhance touch detection accuracy.
HOLTEK New HT32F61730/741 Li-Battery Management MCUs
Holtek announced the release of two new Li-Battery management MCUs, the HT32F61730 and HT32F61741. Compared with the second generation HT32F61630 and HT32F61641 devices...
HOLTEK New HT45R6Q-2/HT45R6Q-3 Battery Charger OTP MCU
Holtek has further expanded its range of battery charger OTP MCUs with the present release of two new devices, the HT45R6Q-2 and HT45R6Q-3...
The BS81xA-x series devices have features such as excellent immunity against power supply variations and a short touch switch response time, thus allowing them to be excellent touch switch solutions for various AC power product applications. Additionally, the low average current characteristic of the series also makes them excellent for use in battery powered products.
The BS812A-1 provides two touch keys and has two corresponding output pins. With a minimum number of external components, this device can implement two touch key functions. With its 6-pin SOT23 package type having an extremely small outline, it is suitable for those application areas where space is at a premium.
The BS8112A-3 and BS8116A-3 respectively provide twelve and sixteen touch key functions. Both devices include an I2C interface which is used to transfer their key status to a host MCU. The host MCU also sends instructions over the I2C interface to instruct the devices to enter their power-saving mode and for sensitivity adjustment. A single power supply decoupling capacitor is the only external component required to implement the touch switch functions. They devices are supplied in 16-pin NSOP and 20-pin SOP/SSOP package types.
