HOLTEK New HT66FB576 USB RGB LED Flash MCU

Published: Dec 01,2016

397 Read

With a focus on the colour RGB LED product application area, Holtek announced the release of its new USB Flash MCU, the HT66FB576. With its USB interface, the device is not only used in general computer peripheral and consumer product applications, but with its integrated constant current source together with 48 PWM outputs, it has the ability to control up to 128 RGB LEDs in a matrix scan configuration.

More on This

HOLTEK New HT32F67233 Sub-1GHz GFSK Transceiver Arm Cortex -M0+ MCU

Holtek announces the release of its new wireless communication dedicated MCU, an Arm Cortex-M0+ core Sub-1GHz GFSK transceiver, the HT32F67233...

HOLTEK New BC66F2143 Sub-1GHz RF Transmitter MCU

Holtek announces the release of its new Sub-1GHz RF OOK/FSK Transmitter Flash MCU, the BC66F2143. This new device, which can operate in the license-free ISM bands...

The RGB LED colour change possibilities can implement breathing effects using the fully internal hardware circuits. This makes this highly functionally integrated MCU suitable for use in colour RGB LED products such as RGB Gaming Keyboards, RGB Gaming Mice, RGB LED Speakers etc. By using this device the need for external PWM components is eliminated resulting in lower costs and reduced product development times.

The device includes 32Kx16 bits of Program Memory, 256 bytes of Data EEPROM and 1K bytes of RAM Data Memory. It also includes a 16-channel 12-bit A/D Converter, SPI, I2C and UART interfaces as well as two LED PWM Data Memory sections each having a capacity of 512 bytes. The hardware can automatically calculate the PWM duty cycle according to the data written into the dedicated Data Memory to implement LED colour changes and breathing effects.

The device therefor extends the functions of the already released HT66FB5x0 and HT68FB5x0 device series. It is provided with an ISP online firmware update function using its USB interface and also supports ICP, ISP and IAP modes to provide a means for easy and fast development for USB related peripheral products.
