HOLTEK New BH66F71662/52 Bluetooth Beacon Transmission Body Fat Scale MCUs

Published: Mar 10,2020

1735 Read

Holtek announces the release of its new Bluetooth Beacon transmission body fat scale Flash MCUs, the BH66F71662 and BH66F71652. The devices include a fully integrated Bluetooth Beacon transmission circuit, body fat scale circuit and 24-bit A/D converter, features which combine to make the devices suitable for use in a variety of four-electrode LED Bluetooth transmission AC body fat scales and other related products.

More on This

HOLTEK New HT32F67233 Sub-1GHz GFSK Transceiver Arm Cortex -M0+ MCU

Holtek announces the release of its new wireless communication dedicated MCU, an Arm Cortex-M0+ core Sub-1GHz GFSK transceiver, the HT32F67233...

HOLTEK New BC66F2143 Sub-1GHz RF Transmitter MCU

Holtek announces the release of its new Sub-1GHz RF OOK/FSK Transmitter Flash MCU, the BC66F2143. This new device, which can operate in the license-free ISM bands...

With regards to MCU resources, the BH66F71662/BH66F71652 devices include a Flash Program Memory capacity of 16K×16/8K×16, a Data Memory capacity of 512×8/384×8, an EEPROM capacity of 64×8/32×8, LED driver and various communication interfaces. The devices include an integrated Bluetooth transmission circuit which can easily implement Bluetooth Beacon transmission functions, thus simplifying product development and production. T

he devices have a fully integrated four-electrode AC body fat circuit which use AC body fat measurement technology to implement more accurate impedance measurements and also greatly reduce the external component requirements. This results in major reductions in BOM costs as well as improved productivity. The internal 24-bit A/D Converter circuit together with the internal LDO can provide power to external sensors for weight measurement purposes.

As for packaging, the devices are supplied in 46-pin QFN package types. With their abundant system resources and comprehensive range of functions, the devices can meet the needs of a wide range of diversified health measurement products.
