The device provides a highly stable transmission quality and is compatible with the market RF 2.4GHz proprietary IC packet format, meeting the requirements of low power consumption and the response requirements of IoT products. It can be widely used in smart homes, industrial/agricultural controllers, etc., to implement stable 2.4GHz wireless two-way transmission.

The BC5602 has an operating voltage range ranging from 1.9V to 3.6V and a programmable transmitting power ranging from -10dBm to +6dBm. Its receiving sensitivity can be up to -98dBm at a data rate of 125Kbps. Its receiving current is 17mA at a data rate of 250/500Kbps. The device also supports a Low Sleep current of 0.5μA, a Middle Sleep Mode for crystal fast wake-up and an ATR (Auto-Transmit-Receive) function.

The BC5602 includes an SPI control interface and meets with the industrial specification operating temperature of -40°C~85°C. It is supplied in a small 16-pin QFN (3mm×3mm) package type which will meet the requirements of low profile wireless product and module designs.
