HOLTEK New Arm Cortex-M0+ Based 32-bit Flash MCU Series HT32F573xx

Published: May 25,2020

1245 Read

Holtek announced the release of its new generation Arm Cortex-M0+ Microcontroller device series, the HT32F57331/57341/57342/57352 series. These new devices include a full range of outstanding features such as their high operating efficiency, an LCD display interface and lower power consumption. These devices are suitable for a wide range of LCD display applications such as health measurement products, smart meters for electricity, water and gas, etc. The HT32F57331/57341 devices support 25 SEG × 8 COM displays while the HT32F57342/57352 devices support 33 SEG × 8 COM displays.

More on This

HOLTEK New HT32F67233 Sub-1GHz GFSK Transceiver Arm Cortex -M0+ MCU

Holtek announces the release of its new wireless communication dedicated MCU, an Arm Cortex-M0+ core Sub-1GHz GFSK transceiver, the HT32F67233...

HOLTEK New BC66F2143 Sub-1GHz RF Transmitter MCU

Holtek announces the release of its new Sub-1GHz RF OOK/FSK Transmitter Flash MCU, the BC66F2143. This new device, which can operate in the license-free ISM bands...

This series include functions such as a high operating speed of 60 MHz and a single power supply with an operating voltage range of 1.65V~3.6V. With regard to memory the devices contain 32~128K bytes of Flash Program Memory and 4~16K bytes of SRAM Data Memory. Additional functions include abundant peripheral resources, such as a USART interface, two UART interfaces, two I2C interfaces, two SPI interfaces, a USB interface and a 10-channel 1 Mbps SAR A/D Converter as well as many others.

The devices also provide a CRC16/32 data checking mechanism and a hardware divider. The HT32F57342/57352 devices contain a 6-channel PDMA, two 500 Ksps 12-bit D/A Converters and a AES-128 hardware encryption mechanism, features which when combined make them suitable for a huge range of applications.

The HT32F573xx devices are supplied in 46-pin QFN and 48/64-pin LQFP package types and contain from 37 to 53 GPIO pins. The HT32F57342/52 devices are supplied in 80-pin LQFP package type and up to 67 GPIO pins. In their low power consumption mode - DeepSleep1/2 - the devices can be woken up from any I/O-pin, which makes the design of power saving mode operation more convenient. The integrated reference voltage is used for A/D Converter measurement calibration and suitable for low-power battery applications.

In addition to being supported by professional IDE suppliers including IAR, the entire series have been licensed by Keil for free use. Additionally, Holtek also provides demo boards and development platform kits. The Holtek development platform includes an ICE e-Link32 Pro, a full set of peripheral driver firmware libraries, application example source code, application development handbooks as well as the GNU GCC and the make compilation environment. The complete series have passed UL/IEC 60730 Class B certification and can provide a related safety test library. With Holtek’s integrated ISP (In-System Programming) and IAP (In-Application Programming) technology, users will find software upgrade implementation an easy and quick process, thus enhancing the efficiency and flexibility of their products.
