With regards to other resources, the BH66F2663 includes a 16K×16 Flash Program Memory, a 1024×8 Data Memory, a 256×8 EEPROM, LED driver and a range of communication interfaces. The device includes an integrated 5kHz~1MHz multi-frequency band sine wave generator, an impedance phase angle measurement circuit, an LDO and a 24-bit A/D converter circuit.

With these features, the device can provide a wide range and more accurate impedance phase angle measurements and also greatly reduce the external component requirements. This results in major reductions in manufacturing and BOM component costs. The EEPROM can be used to store any required automatic adjustments for the product as well as calibration parameters thus simplifying development and production.

With regards to packaging, the BH66F2663 is supplied in 48-pin LQFP and 64-pin LQFP package types. With its abundant system resources and comprehensive range of functions, the device can meet the needs of a wide range of diversified health measurement products.
