HOLTEK New HT68F2420 IR Driver MCU

Published: Dec 07,2020

908 Read

Holtek announced its new IR driver MCU, the HT68F2420. This new device is suitable for IR remote controllers and IR transmission related products. As the device includes fully integrated high accuracy oscillators and an IR LED driver circuit, IR applications do not require an external oscillator or drive transistor, thus saving on external component costs and effectively improving production efficiency.

More on This

HOLTEK New BS84C12CA High Noise Immunity Enhanced Touch A/D MCU

Holtek announced the release of its new Enhanced Touch A/D Flash MCU, the BS84C12CA. This new device incorporates all th...

HOLTEK New BP66FW1242 Wireless Charger Rx MCU

Holtek announced the release of its new WPC Qi certified, sub-5W wireless charger receiver MCU, the BP66FW1242. The devi...

The device includes an internal integrated adjustable IR carrier frequency generator, the generated frequency range of which is 4kHz to 1MHz. By using Holtek’s development tool, four common IR carrier frequency options of 36/38/40/56kHz are provided as well as the internal oscillation frequency which can be adjusted to 3.996/3.99/4.0/3.976MHz. This effectively reduces the frequency division error making the IR transmitter carrier frequency more compatible with the IR receiver carrier frequency, which will increase the IR transmission distance.

The device has an operating voltage range of 1.8V~5.5V. With regards to other system resources, the device has a Flash Program Memory capacity of 1K×13, a Data Memory capacity of 32×8, a 9-bit Timer and a Time Base. The internal high frequency oscillator has a fixed frequency of 4MHz with an accuracy of up to ±0.4% and an IR LED drive current which can be up to 500mA. With regards to packaging, the device is supplied in 8-pin SOP, 16-pin NSOP and 20-pin NSOP/SSOP package types.
