New Clock and Timing Chip with 14-GHz Fractional-N PLL
Published: Jun 10,201424 Read
The LMX2492/92-Q1 is a low noise 14 GHz wideband delta-sigma fractional N PLL with ramp and chirp generation. It consists of a phase frequency detector, programmable charge pump, and high frequency input for the external VCO.
Smallest Data Converters Deliver High Integration and Performance
Texas Instruments (TI) introduced four tiny precision data converters, each the industry’s smallest in its class. The ...
TI Introduces a New Family of LED Drivers with 12-bit PWM, 29-kHz Dimming Frequency
First 12-bit, 29-kHz RGB LED Driver Family Enables Vivid Color and Seamless Animation with Zero Audible Noise Texas I...
The LMX2492/92-Q1 supports a broad and flexible class of ramping capabilities, including FSK, PSK, and configurable piecewise linear FM modulation profiles of up to 8 segments.It supports fine PLL resolution and fast ramp with up to a 200 MHz phase detector rate. The LMX2492/92-Q1 allows any of its registers to be read back.
The LMX2492/92-Q1 can operate with a single 3.3 V supply. Moreover, supporting up to 5.25 V charge pump can eliminate the need of external amplifier, leading to a simpler solution with improved phase noise performance.
Features:
－ -227 dBc/Hz Normalized PLL Noise
－ 500 MHz – 14 GHz Wideband PLL
－ 3.15 – 5.25 V Charge Pump PLL Supply
－ Versatile Ramp / Chirp Generation
－ 200 MHz Max Phase Detector Frequency
－ FSK / PSK Modulation Pin
－ Digital Lock Detect
－ Single 3.3 V Supply Capability
－ Automotive 125°C Q100 Grade 1 Qualification
－ Non-Automotive (LMX2492) Option
