New 1.2kV, 120A Half-Bridge Module for 30-60kW Power Conversion Systems

Published: Dec 10,2014

510 Read

Cree announces the release of a new 1.2kV 120A half-bridge module (CAS120M12BM2) that brings game-changing SiC-based performance and system-level cost savings to 30 kW - 60 kW power conversion systems.

More on This

Cree and STMicroelectronics Expand and Extend Existing Silicon Carbide Wafer Supply Agreement

Cree and STMicroelectronics announced today the expansion and extension of an existing multi-year, long-term silicon car...

Cree and STMicroelectronics Announce Multi-Year Silicon Carbide Wafer Supply Agreement

Cree announces that it signed a multi-year agreement to produce and supply its Wolfspeed silicon carbide (SiC) wafers to STMicroelectronics...

Powered by C2M MOSFET technology, the new module offers an industry low 2.1 mJ of total switching losses that is 14x lower than similarly rated IGBT4 modules. Positioned as a lower priced alternative to the existing high reliability CAS100H12AM1 module, the new CAS120M12BM2 module facilitates an easy design-in experience due to the well known, industry standard 62 mm package and the simple drive requirements of the C2M MOSFETs.

The new module represents a new price/performance paradigm for SiC technology, enabling simpler, lower cost systems with higher efficiency and reliability in applications such as induction heating, battery chargers, DC/DC converters, solar inverters, and line regenerative motor drives.

The CAS120M12BM2 module is stocked and available for immediate purchase at authorized Cree distributors such as Digi-Key, Mouser, and Richardson RFPD/Arrow RF & Power.

Features:

- Ultra-low loss

- High-efficiency operation

- Zero reverse-recovery current from diode

- Zero turn-off tail current from MOSFET

- Normally-off, fail-safe device operation

- Ease of paralleling

- Copper baseplate and aluminum-nitride insulator
