Industry's First Cable Driver to Support SDI- and IP-Based 4K Video
Published: Apr 06,20151120 Read
Texas Instruments (TI) introduced the industry's first cable driver to support uncompressed 4K ultra high definition (UHD) video transmission using serial digital interface (SDI) and 10 gigabit Ethernet (GbE) protocols. The LMH1218 gives engineers the flexibility to design video infrastructure equipment for SDI or Internet protocol (IP) formats with a single component. T
Smallest Data Converters Deliver High Integration and Performance
Texas Instruments (TI) introduced four tiny precision data converters, each the industry’s smallest in its class. The ...
TI Introduces a New Family of LED Drivers with 12-bit PWM, 29-kHz Dimming Frequency
First 12-bit, 29-kHz RGB LED Driver Family Enables Vivid Color and Seamless Animation with Zero Audible Noise Texas I...
Featuring an integrated reclocker, the LMH1218 supports both coax cable and optical media for uncompressed video transmission inside buildings and over long-haul networks. Saving up to 40 percent board space compared to competitive solutions, this integration simplifies the design of applications such as broadcast video routers and switches, digital signage, test and measurement equipment, medical imaging, and security and surveillance equipment.
"With broadcasters and video professionals looking to use 60p and create more 4K content, upgrading SDI infrastructure to use a single cable to transmit 12 Gbps of data for 4K uncompressed video transmission is essential," said Grant Petty, CEO of Blackmagic Design.
"The integrated capabilities of TI's LMH1218 cable driver are helping us quickly design new and improved 12-Gbps SDI products, and I can't wait to see the new content. In particular, 60p is something that broadcasters are starting to use now; enabling 12-Gbps SDI throughout will allow them to build out an efficient 4K workflow to handle 60p."
Features:
－ Transport flexibility: Supports SDI and IP-based video infrastructure, allowing engineers to use a single device for either output or design end equipment with both output options.
－ Reduced system complexity: An integrated referenceless reclocker eliminates the need for external components to transmit over either optical or coax media. Competing solutions require two or more devices to support each media type.
－ High data rate: Transmits up to 12 Gbps, enabling UHD resolution of 4K at a 60p frame rate over a single coax cable.
－ Low power: Typical power consumption is 300 mW, which on average is 30 percent lower than a discrete solution of cable driver and reclocker.
－ Board diagnostics: The eye-monitor function plots incoming signals and detects vertical or horizontal eye openings, which can be used to enhance system reliability.
