Toshiba Launches Sensorless Control Pre-Driver IC for Automotive BLDC Motors

Published: Mar 28,2019

118 Read

Toshiba announced the launch of a sensorless control pre-driver IC “TB9062FNG” for brushless DC motors (BLDC motors) used in automotive applications, including electric pumps. Samples are available now, with mass production scheduled for December this year.

More on This

Toshiba Adds BiCS FLASH Enabled UFS to Lineup of Embedded Flash Memory for Automotive

Toshiba Memory Corporation announced that it has begun sampling new Automotive JEDEC UFS Version 2.1 embedded memory solutions utilizing 3D flash memory...

Toshiba Brings Arm Cortex-M core-based MCUs to Thundersoft's MCU Boards

Toshiba Electronic Devices & Storage Corporation has today started to supply “TMPM3HQFDFG” microcontroller for use in general-purpose MCU boards manufactured by Thundersoft...

The new pre-driver can control BLDC motors by pulse-width modulation (PWM) input only, without any need for high-performance MCUs and software.

TB9062FNG has an automatic duty generation function that adjusts the output PWM duty cycle to suit the battery voltage (VBAT) at startup, and a soft speed changing function that prevents stalls by suppressing sudden changes in output PWM duty. These functions, which were absent from Toshiba’s earlier products, contribute to stable motor control.

TB9062FNG does not require any software development as it is controlled by a hard-wired logic circuit. VBAT over voltage detection, VBAT under voltage detection, over current protection, and thermal shutdown circuits are also implemented. The operating temperature range is -40°C to 125°C, highly suited to automotive applications.
